LM324 (Pack of 5)

(0)

? Internally Frequency Compensated for Unity Gain

? Large DC Voltage Gain 100 dB

? Wide Bandwidth (Unity Gain) 1 MHz (Temperature Compensated)

? Wide Power Supply Range: ? Single Supply 3 V to 32 V ? or Dual Supplies ?1.5 V to ?16 V

? Very Low Supply Current Drain (700 ?A) ?Essentially Independent of Supply Voltage

? Low Input Biasing Current 45 nA (Temperature Compensated)

? Low Input Offset Voltage 2 mV and Offset Current: 5 nA

? Input Common-Mode Voltage Range Includes Ground

? Differential Input Voltage Range Equal to the Power Supply Voltage

? Large Output Voltage Swing 0 V to V ? 1.5 V

Quantity:

Total: ₹ 130

LM358 (Pack of 5)

(0)

Short Circuit Protected Outputs
True Differential Input Stage
Single Supply Operation: 3.0 V to 32 V
Low Input Bias Currents
Internally Compensated
Common Mode Range Extends to Negative Supply
Single and Split Supply Operation
ESD Clamps on the Inputs Increase Ruggedness of the Device without Affecting Operation
NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC?Q100 Qualified and PPAP Capable
